General Purpose Checkweigher Standard Automatic Check Scale
Industrial Precise Weighing Machine
YCW-210 / YCW-300 suitable for detecting the overweight and
underweight for small and medium-sized packaged goods;
Optional Rejecting methods: swing rod, turning plate, blowing, push
rod, diversion, etc.
Parameter
| Model | YCW-300 |
| Power Supply | AC220V±10% 50Hz(60Hz) |
| Rated Power | 0.4KW |
| Checking Range | ≤3000g |
| Accuracy | ±0.5g~±2g |
| Minimum Scale | 0.1g |
| Belt Speed | 20～90m/min |
| Suggested Product Dimension | ≤300mm L * 290mm W |
| Weighing Belt Dimension | 450mm L*300mm W |
| Machine Dimension | 1800mm(L)*860mm(W)*1222mm(H) |
| Rejector | Swing arm/Pusher |
| Control Module | High Speed A/D Sampling Module |
| Product Preset | 99 |
| Conveyor Direction | From Left to Right (Right to left optional) |
| Compressed Air | 0.6-1Mpa |
| Nozzle Connector Type | Φ8mm |
| Operating Requirement | Temperature: 0℃～40℃,Humidity:30%～95% |
| Machine Body Construction | SUS304 Full Stainless Steel |
Measurement
Related Products
Company Information
Exhibition
FAQ
1. Are you a manufacturer or trader?
A:We are manufacturer, we have own factory in China, integrated
with R&D, Production, Selling.
2,How to choose the most suitable products ?
A:Our professional team will give you the best suggestion as long
as you tell us what kind of food you need to check and the required
specification.
3,Can you provide special design and configuration for us ?
A:Customized production available, special production available as
per customer drawing.
4,What is lead time of this products ?
A: The lead date is about 20-25 days.
5, How many years warranty for this product ?
A: We can give 1-year warranty for machine.
6,How to install and use the product ?
A: The product is shipped with an operating instructions and video
of English version.
7,How about your after-sale service ?
A: Within 1-hour email response for machine issues and within 4
hours offer for machine trouble shooting solution. Fast and in time
contact for technical support via live chat tool group. (WA, Viber,
WeChat, etc.) Fastest courier delivery for the spare parts once
confirmed the problems caused by parts.
Overseas engineer deployment available if necessary.
Training support available for customer at our factory.
